Choose a speaker layout to suit your room, from a space-saving 2.1-ch setup enhanced with 3D surround-sound courtesy Dolby Atmos Height Virtualizer* or DTS Virtual:X® to a 3.2.2-ch system for native object-audio playback.

Whatever way you play it, dynamic power is ready to thrill thanks to authentic high-current analog amps backed by a thumping custom transformer. For true-to-life video, the AVR supports 4K/60p and HDR video passthrough.

If all this tech sounds scary, relax: every aspect of this product is designed to erase frustration, from the automated AccuEQ system calibration to quick connection guide. The receiver integrates your players and TV and adds practical features such as Vocal Enhancer for clear dialog.

There’s even a Zone B line-out to distribute all your home theater sources to a component with an analog RCA line in, such as a wireless headphone dock or hi-fi system.

Or just sit back and stream from apps via Bluetooth® technology and let Advanced Music Optimizer™ enrich every note of the golden Onkyo sound.

Power output (All channels)
80 W/Ch (8 Ohms, 20 Hz–20 kHz, 0.08% THD, 2 Channels Driven, FTC)
155 W/Ch (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)
THD+N (Total Harmonic Distortion + Noise)
0.06% (20 Hz–20 kHz, 8 Ohms, 1 Channel Driven, 50 W)
Input sensitivity and impedance
200 mV / 47k Ohms (Line)
Frequency response
10 Hz–100 kHz /+ 1 dB, -3 dB (Direct Mode)
Tone control
±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
Signal-to-noise ratio
109 dB (Line, IHF-A)
Speaker impedance
4 Ohms–16 Ohms
Tuner
